Raman Amplifer Equipment

Description

Easy control and operation: Dual CPU process control Loops.

Types of Raman Amplifier

Diagram

Features

Distributed low-noise amplification.

Easy control and operation: Dual CPU process control Loops.

Interface respectively.

High stability and reliability.

Single-channel, DWDM, or C+L band is available.

Intelligent temperature control system: power consumption and hot.

Radiation reduces 30% than common products.

Pump polarization-Independent design.

Technical Specifications

Environmental Requirements

Table 2-1 Environmental Characteristic

Note: non-condensing

Mechanical/ Power/ Interface Characteristics

Table 2-2 Mechanical/ Power/ Interface Characteristics

(1) Actual consumption depends on the output power and environment
temperature.

(2) 110VAC, 220VAC and -48VDC is optional.

Optical Specifications

Table 2-3 Optical Characteristics

Parameter	Symbol	Min	Typ	Max	Units
Operating wavelength	λc	1525	1550	1565	nm
Pump wavelength	λp	1425	——	1505	nm
Pump output power(1)	Po	——	500	1000	mW
ON/OFF Gain(1)	G	6	——	15	dB
Gain Flatness(2)	FL	——	1	2	dB
Polarization Dependent Gain	PDF	——	——-	0.3	dB
PMD	PMD	——	——-	0.3	ps
Relative Noise Figure	NF	——	——	0	dB

(1) Optional.

(2) Test at 0 dBm input.
